PRODUCT DESCRIPTION
LD MAUI G3 MIX SERIES 21
9
SIG
- Indicates that an audio signal is present at the corresponding channel (white LED). If the signal is
clipping the LED turns red.
10
SELECT buttons
- Toggle between MIC, LINE and HI-Z.
11
HOLD TO LINK button
- Push and hold for 2 seconds to activate Bluetooth® pairing for audio streaming.
12
PAGE button
- Browses through the menu pages. Hold for 1 second to access the settings.
13
Mute MAIN
- Indicates that the main channel is muted
14
MAIN Rotary-Push Encoder (RPE)
- Controls the main volume and mute for the main channel. Hold to
mute or unmute. Lights up orange in SysLink® remote mode.
15
SYSLINK button
- Push to access the remote unit connected via SysLink®
16
LIMIT
- Indicates that the main limiter is active
17
FOOTSWITCH
- Mutes and unmutes the internal effect module or the MAIN channel (6.3mm TRS jack)
18
SYSLINK socket
- RJ45 SysLink® socket
19
INPUT 3/4
- Balanced XLR/jack combo sockets (3-pin XLR / 6.35 mm jack / 48 V phantom power not sup-
ported).
20
INPUT 1 and 2
- Balanced XLR / jack combo sockets (3-pin XLR / 6.35 mm jack / 48V phantom power sup-
ported)
21
MONITOR 1 and 2
- Audio output sockets (balanced 3-pin XLR) for external monitors
22
SYSTEM OUT
- Audio output socket (balanced 3-pin XLR)
5.7 EASY MODE AND EXPERT MODE
The MAUI® G3 MIX System features an Easy Mode with a reduced user interface for beginner users. If you like
to access the system's full functionality, activate the Expert Mode. The layout of some of the pages of the user
interface differs from Easy Mode to Expert Mode. For an overview of the user interface layouts, refer to the
overview sections in the user manual.
In Expert Mode and Easy Mode, volume levels are scaled differently. In Easy Mode, the decibel unit is not indic-
ated.
EXAMPLE:
Expert Mode -inf dB...+10.0 dB
Easy Mode 0...100
See also:
Expert Mode Overviews [}32]
Easy Mode Overviews [}53]
GLOBAL Settings Overview [}48]
