PRODUCT DESCRIPTION
20 LD MAUI G3 MIX SERIES
DSP CHARACTERISTICS
Article number LDMAUI11G3MIX(W) LDMAUI28G3MIX(W)
AD/DA converter bit depth 24Bit 24Bit
AD/DA converter sampling fre-
quency
48kHz 48kHz
5.6 THE USER INTERFACE
REMOTE
LIMIT
1
2
8
4
12
11
14
15
19
17
18
20 21 22
5
3
10
6
16
13
9
7
1
Channel 1 Rotary-Push Encoder (RPE)
- Controls the volume and mute for channel 1. Hold to mute or
unmute. Lights up orange in SysLink® remote mode.
2
Channel 2 Rotary-Push Encoder (RPE)
- Controls the volume and mute for channel 2. Hold to mute or
unmute. Lights up orange in SysLink® remote mode.
3
Channel 3/4 Rotary-Push Encoder (RPE)
- Controls the volume and mute for channels 3/4. Hold to
mute or unmute. Lights up orange in SysLink® remote mode.
4
Channel BT Rotary-Push Encoder (RPE)
- Controls the volume of the Bluetooth® channel. Hold to mute
or unmute. Lights up orange in SysLink® remote mode.
5
LC Display
- Main graphic colour display. Display edges turn orange in SysLink® remote mode. For
screensaver options, see the display settings.
6
Brightness sensor
- Automatically adjusts the display brightness. Turn on or off in the display setttings.
7
Mute CHANNELS
- Indicates that the channel is muted
8
Display Rotary-Push Encoders (RPE)
- Control the display menu items (Upper RPE, Mid RPE, Lower RPE)
