9
www.lavorwash.com.au
LAVOR - IFH-175
USER MANUAL
175,000BTU - Industrial Fan Forced Heater
Electrical System Protection:
• The heater’s electrical system is safeguarded by a fuse mounted on the PCB Assembly. This protects the
electrical components from damage.
• If the heater fails to operate, inspect and replace the fuse as needed.
Flame-Out Sensor:
• A photocell monitors the ame in the combustion chamber during operation.
• If the ame goes out, the sensor automatically shuts o the heater for safety.
FUELING INSTRUCTIONS
• NEVER ll the heater’s fuel tank in living spaces; always ll the tank outdoors.
• Avoid overlling the tank, and ensure the heater is placed on a level surface.
• NEVER rell the fuel tank while the heater is operating or still hot.
Important: First Ignition
When lighting the heater for the rst time, do so
outdoors. This will allow any oils or residues from
manufacturing to burn o safely.
FRESH AIR VENTILATION
Provide a fresh air opening of at least three (3) square
feet (2,800 sq. cm) for every 30,000 kcal/Hr. rating.
TO START HEATER
1. Fill the fuel tank with kerosene or diesel
2. Securely attach the fuel cap.
3. Plug the power cord into a three-prong, grounded extension cord (at least six feet long).
Extension Cord Wire Size Requirements:
6 to 10 feet (1.8 to 3 meters): Use 18 AWG conductor.
11 to 100 feet (3.4 to 30.53 meters): Use 16 AWG conductor.
101 to 200 feet (30.8 to 61 meters): Use 14 AWG conductor.
4. Turn the THERMOSTAT CONTROL KNOB to the desired setting and push the power switch to the “ON” position.
The power indicator lamp will light, and the heater will start.
If the heater does not start:
Adjust the thermostat to a higher setting. If it still doesn’t start, turn the power switch o and then back on.
Refer to the Troubleshooting Chart if necessary.
Note: The heater’s major electrical components are protected by a safety fuse mounted on the PCB board.
If the heater fails to start, check and replace the fuse as necessary. Ensure the power source is supplying the
correct voltage and frequency.
TO SHUT DOWN HEATER
1. Turn the power switch to “OFF.”
2. Unplug the power cord.
TO RESTART HEATER
1. Wait 10 seconds after stopping the heater.
2. Follow the steps under “To Start Heater.”
