Lantronix ION x222x / x32xx Install Guide
33433 Rev. D https://www.lantronix.com/ Page 8 of 42
SIC: Powered by the Chassis
Environment 0 to 50°C (32 to 122°F) operating;
5% - 95% humidity (non-condensing)
0 to 10,000 ft. altitude
Storage Temp -40 to 85°C (-40 to 185°F)
C2220 Series
Standards IEEE Std. 802.3, IEE std. 802.3ah, IEE Std. 802.1P, IEEE std. 802.1Q
Data Rate Copper: 10/100/1000Mbps
Fiber: 100Mbps
Filtering Address 8K MAC Addresses
Power Consumption 4.5 Watts
Shipping Weight 1 lb. [.45 kg]
Regulatory Compliance EN55022 Class A, EN55024, CE Mark
C322x Series
Standards IEEE Std. 802.3, IEEE Std. 802.3ah, IEEE Std 802.1P,
IEEE Std 802.1Q
Data Rate Copper: 10/100/1000Mbps
Fiber: 1000Mbps
Max Frame Size 10,240 bytes
Power Consumption 4.5 Watts
Shipping Weight 1 lb. [.45 kg]
Regulatory Compliance EN55022 class A, EN55024, CE Mark
The physical specifications for the chassis slide-in modules are described in Table 4 below.
S322x Series
Standards IEEE Std. 802.3, IEEE Std. 802.3ah, IEEE Std 802.1P,
IEEE Std. 802.1Q
Data Rate Copper: 10/100/1000Mbps
Fiber: 1000Mbps
Max Frame Size 10,240 bytes
Dimensions Width: 3.25” [82 mm]
Depth: 6.5” [165 mm]
Height:1.0” [25 mm]
Power Input: 100-240VAC, 1A
Output: 12VDC, 1.25A
Shipping Weight 2.0 lbs. [0.90 kg]
Regulatory Compliance EN55022 Class A, EN55024, UL60950, CE Mark
