Lantronix ION x222x / x32xx Install Guide
33433 Rev. D https://www.lantronix.com/ Page 7 of 42
• *S3221-1040-T: 10/100/1000Base-T (RJ-45) [100 m] to (2) 100/1000Base-x Open SFP Slots,
Extended Operating Temp Range
C3220 Series
• C3220-1014: 10/100/1000Base-T (RJ-45) [100 m] to 1000Base-LX 1310nm single mode (SC) [10
km/6.2 mi.] Link Budget: 10.5 dB
• C3220-1040
*: 10/100/1000Base-T (RJ-45) [100 m] to (1) 100/1000Base-X SFP Slot (empty)
• C3221-1040
*: 10/100/1000Base-T (RJ-45) [100 m] to (2) 100/1000Base-X SFP Slots (empty)
Compatible Accessories (Sold Separately)
WMBL: 4″ [102 mm] Fits Stand-Alone Converters size 4.8″ [122 mm] and 6.5″ [165 mm]
RMS19-SA4-02: 4-Slot Media Converter Shelf, includes 4 brackets and 3 slot blanks
WMBD: 5″ [127 mm] DIN Rail Mount Bracket Fits all Stand-Alone Converters; 1- or 2-Slot ION Chassis
SFP Modules:
SFP modules supported on some slide-in cards; see the Lantronix SFP webpage.
Note: all units feature USB port for local management application.
* C3220-1040 and C3221-1040 have SGMII support for use with 10/100/1000Base-T copper SFPs.
Features
See the x222x / x32xx Web User Guide for features.
• MEF 9, 14 and 21 certified
• IEEE 802.3ah Link OAM
• 10K Jumbo Frame Support
• Two selectable Remote Management
modes:
o IP-Based Remote Management
o In-Band (remote device managed by
local peer)
• Auto-MDI/MDIX
• Auto-Negotiation
• Pause
• Transparent Link Pass Through
• Far-End-Fault (FEF)
• Remote Loopback
• Field Upgradeable Firmware
• IEEE 802.1p QoS packet classification
• IPv4 IP TOS, DiffServ and IPv6 traffic
class QoS classification
• IEEE 802.1Q VLAN and double VLAN
tagging with 4096 VIDs
• DHCP client
• SNTP
• TFTP
• RADIUS client
• RMON counters for each port
• Bandwidth profiling
• DMI Optical Management
• Cable diagnostic function for copper
ports
• SSH
• Telnet
• Command Line Interface (CLI)
• Web management
• SNMP v1, v2c, and v3
• USB port for basic setup
• Management VLAN
Physical Specifications
The physical specifications for the chassis slide-in modules are described ibelow.
All Model x222x / x32xx
Dimensions SIC: 3.4” x 0.86” x 6.5” (86 mm x 22 mm x 165 mm)
Standalone: 3.25” x 1.0” x 6.5” (82 mm x 25 mm x 165 mm)
MAC Filtering 8K MAC addresses
Power Input Standalone: 12VDC @ 375mA
