WLAN profile settings*
Up to 26 non-overlapping channels (available channels and further obligations such as automatic DFS dynamic
channel selection depending on national regulations)
Radio channels 5 GHz
Up to 13 channels, max. 3 non-overlapping (depending on country-specific restrictions)Radio channels 2.4 GHz
Depends on the access points in operationConcurrent WLAN clients
Managed LANCOM Access Points support the WLAN standard IEEE 802.11u (Hotspot 2.0) which allows mobile clients
a seamless transition from the cellular network into WLAN hotspots. Authentication methods using SIM card
information, certificates or username and password, enable an automatic, encrypted login to WLAN hotspots of
roaming partners - without the need to manually enter login credentials
IEEE 802.11u
Seamless handover between radio cells, IAPP support with optional restriction to an ARF context, IEEE 802.11d
support
Roaming
Opportunistic key caching allows fast roaming processes between access points. WLAN installations utilizing a
WLAN controller and IEEE 802.1X authentication cache the access keys of the clients and are transmitted by the
WLAN controller to all mananged access points
Opportunistic Key Caching
Based on IEEE 802.11r, allows fast roaming procedures between access points. This is possible by using IEEE 802.1X
authentication or pre-shared keys in controller based WLAN installations, which save the access keys temporarily
and distribute them to the managed access points.
Fast roaming
WPA3-Personal, IEEE 802.11i / WPA2 with passphrase (WPA2-Personal) or IEEE 802.1X (WPA3-Enterprise,
WPA2-Enterprise) and hardware-accelerated AES, closed network, WEP64, WEP128, WEP152, user authentication,
IEEE 802.1x /EAP, WPA1/TKIP, LEPS-MAC, LEPS-U
Security
time-based activation and deactivation of WLAN networksTime Control
Prioritization according to Wireless Multimedia Extensions (WME, subset of IEEE 802.11e)Quality of Service
Rogue WLAN client detection based on probe requestsClient detection
Coding method according to IEEE 802.11n. The Space Time Block Coding improves reception by coding the data
stream in blocks.
Space Time Block Coding (STBC)*
Low Density Parity Check (LDPC) is an error correcting method. IEEE 802.11n uses convolution coding (CC) as
standard error correcting method, the usage of the more effective Low Density Parity Check (LDPC) is optional.
Low Density Parity Check (LDPC)*
Depends on the access points in operation*) Note
Security
WPA3-Personal, IEEE 802.1X (WPA3-Enterprise, WPA2-Enterprise), IEEE 802.11i (WPA2-Personal), Wi-Fi Certified™
WPA2™, WPA, WEP, IEEE 802.11w (Protected Management Frames), LEPS-MAC (LANCOM Enhanced Passphrase
Security MAC), LEPS-U (LANCOM Enhanced Passphrase Security User)
Encryption options
AES-CCMP AES-GCMP, TKIP, RC4 (only used by WEP)Encryption
EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-FASTEAP types (authenticator)
LANCOM WLC-2000
LCOS 10.80 lancom-systems.com
4 LANCOM Data sheet - Wireless LAN
