18
www.howdens.com
Where to nd the model
and serial number on
the cooker hood.
Inside the body of the
cooker hood
Declaration of conformity
We declare that our products meet the applicable
European Directives, Decisions and Regulations and
the requirements listed in the standards referenced.
EC Regulation 1275/2008 for standby
Technical specications
LAM2709 / LAM2710: Black Tempered Glass Angled Cooker Hood
General
Total Input Power LAM2709: 78W LAM2710: 78W
Fuse 3 A
Supply Voltage 220V — 240V
Mains Lead Length and Type 1.5m / 3 Core power cord without plug
Speeds 3
Lamps 2 x 1.5 W LED 6500 K
Lighting Efciency Class A
Carbon Filter (not supplied) LAM2010
Grease Filter 1 Aluminium lter (5 layers)
Air Outlet Diameter 150mm
Air Outlet Cable Grid Included
LAM2709 Dimensions
Item Height Width Depth Chimney Heights Minimum Maximum
Extractor Body (mm) 370 600 375 Overall Body Height 770mm 1150mm
Top Chimney Piece (mm) 400 222 172 Ceiling Height N/A N/A
Lower Chimney Piece 400 222 172 Height from hob 650mm 750mm
LAM2710 Dimensions
Item Height Width Depth Chimney Heights Minimum Maximum
Extractor Body (mm) 370 900 375 Overall Body Height 770mm 1150mm
Top Chimney Piece (mm) 400 222 172 Ceiling Height N/A N/A
Lower Chimney Piece 400 222 172 Height from hob 650mm 750mm
