11
22. TAGLINE
Description, Installation and Usage
A tag line is a separate line that is used exclusively for allowing the SRL’s line to retract back into the housing during non-use. The tag line
is attached to the SRL’s connecting hook and is long enough to allow the SRL line to retract fully.
It is recommended that a tag line should be used to let the line on a SRL to fully retract back into the housing during extended periods
(any time span that is greater than 24 hours) of non-use. When a retracting line is left out for extended periods of time , it may weaken the
SRL’s retraction spring quite prematurely hence affecting the operation of the SRL. These taglines are made of nylon string, connected
to a simple snap hook at one end.
Kstrong SRL’s (UFS350025, UFS310060R and UFS310100R) are provided with taglines of appropriate length. When disconnecting the
self-locking snap hook of the SRL from the dorsal D-ring of the full body harness, and while the SRL casing is anchored at a height, then
use the tagline to retract the extended line back to the casing.
• Connect the tagline snap hook to the snap hook of the SRL at its eye.
• Now slowly release the taught extended lifeline while guiding it with the nylon tagline.
• When the entire lifeline of the SRL is retracted into its casing, then hold the tagline in place by tying it securely around a post.
• When you have to pull down the lifeline, just open up the tagline, and pull it down to bring down the lifeline along with it.
• Always use the tagline to retract the lifeline or to extend it slowly.
• Always fold the tagline and keep it in a secure area when not in use.
23. ABOUT LEADING EDGE AND USAGE OF SRL ON IT
Almost all Self Retractable Lifelines are designed only to be mounted above the user. In few exceptional cases where this is not easy
to use the regular SRL, KStrong provides specially designed Leading Edge - Self Retractable Lifelines. These LE SRL’s are specially
designed factors to absorb the extra energy associated with foot-level tie off. These SRL’s have robust ropes/cables that prevent breaking
when rubbed against a leading edge.
Few examples of leading edge:
LE range of SRL’s
The KStrong SRL-LE (UFS310018L, UFS310025L and UFS310050L) are engineered such that in the event of a fall from the edge of
a roof or a terrace, if subjected to contact with a sharp edge, the retracted lanyard remains intact, while arresting the fall immediately.
This range of SRL-LE are suitable for use on edges having radii not greater than 0.005 inch. For this range of SRL-LE the position of the
anchorage point can be at the foot level.
WARNING
Never use the tagline as a safety line. The tagline is NOT a part of fall arrest system. It is only an accessory to the SRL, and it should
NEVER be used as an extension to the lifeline.
Structural steel I-Beams and purlins. Steeldeckandmetalroong
