10
Step 1: Check the housing of the SRL for the presence of distortion, cracks or any damage.
Step 2: Inspect the swivel eye for any distortion. It should turn freely.
Step 3: Check the screws on the housing; they should not be loose or bent or damaged.
Step 4: The labels on the SRL should be intact, and should have the complete inspection log information.
Step 5: Check the functionality of the SRL. The lifeline should fully extend and retract smoothly, and should not cause any slack in
the line. The device should also lock up properly when the lifeline is jerked sharply.
Step 6: Look for signs of corrosion on the entire unit.
Step 7: Extend the full length of the wire rope from the casing. Hold small lengths of the wire rope between both hands, and bend
the rope in an inverted U shape. Look out for the presence of kinks, broken wires, bird caging, corrosion, welding splatter,
chemical damage, or excessively abraded areas. Check the thimble and the swaging on the end of the line; it should not
be torn or broken. Crushed or bent cable, or kinks on the cable may cause the SRL to malfunction, and make it potentially
unsafe for use. Welding damage could result in fused wires, and may alter the strength of the wire.
Step 8: For the webbing lifeline, extend the entire length of the lifeline from the casing of the SRL, and inspect the full length of the
webbing for the presence of any cuts, broken webbing, burns, cuts, abrasions, chemical or heat damage, excessive soiling,
etc.
Step 9: Inspect the connecting hooks and carabiners for signs of damage, corrosion, or excessive wear. Also check that they are
functioning properly.
Record the results of the inspection in the Inspection and Maintenance Log found in this manual. Also tick off clearly on the Label sticker
wherespecied.Iftheequipmentisfoundtobeunsuitableforuse,itshouldbeimmediatelyremovedfromserviceanddestroyed,orsent
to KStrong or to a KStrong authorized service center for repair.
Do not attempt to repair the equipment on your own.
WARNING
Inspect all the other components of the Fall Arrest, Work Positioning, Rescue systems that are to be used, as per the manufacturer’s
instructions.
Removefromuseimmediatelyiftheequipmentshowsevidenceofhavingarrestedafall,orifitisuntforfurtheruse.
It is important to ensure that the connecting elements of the connectors are compatible in size and shape, while making a connection with
the hooks and carabiners.
Never connect a hook to a hook, or a carabiner to a carabiner, or a carabiner to a hook.
Also make sure not to connect a connector to any element that may cause the hook or carabiner material to distort, abrade or wear out.
20. CHOOSE THE RIGHT ANCHORAGE POINT FOR THE SRL
Select the anchorage which should be strong enough to take the load of application. The anchorage should be able to sustain a static
load of a minimum 5000 lbs. in the direction applied by the personal fall arrest system. The anchor point should always lie directly above
the user. Do not work above the anchorage point. The anchor point should also be located in such a place that the swing fall is minimized.
Also, while using the SRL, make sure that there is constant tension in the lifeline, and that there is no slack. If the cable is not taught,
then this could increase the fall distance. Also, move normally because sudden jerky movements may cause the locking mechanism of
the SRL to activate.
21. INSTALLATION OF SRL ON OVERHEAD ANCHOR POINT
Asastationarydevice,theSRLhastobemountedonanapprovedxedanchoragepointwhichisdirectlyoverheadtheuser.Connect
the swivel eye of the SRL with a self-locking carabiner to the overhead anchorage. Connect the snap hook at the end of the lifeline to the
Dorsal attachment D-ring of the Full body harness. The SRL would extend as the user moves away from the anchor point, and retracts as
the user moves back towards the anchor point.
Iftheanchorageismobile,overasteelcableoraxedrail,thentheswiveleyeoftheSRLisconnectedtotheanchorpointwiththehelp
of a self - locking carabiner. The snap hook at the end of the SRL is connected to the dorsal D-ring of the Full body harness of the user.
Here, since the anchor moves along with the user, the SRL travels along with the anchor from one point to the other.
