4
CONNECTIONS USING CONNECTORS:
Ensure that only self-locking snap hooks and carabiners are used with this equipment. All connections should be compatible in size, shape and
strength. The connectors used should be suitable to each application. Ensure that they are fully closed and locked while in use.
NEVER USE INAPPROPRIATE CONNECTIONS:
While using KStrong snap hooks and carabiners, they should not be connected as below:
• Two or more connectors should never be attached to a single D-ring.
• Never attach a connector that could result in a load on its gate.
• Connectors should not be connected in a false engagement. It should be visually conrmed that the connector is fully engaged to the
anchor point. Avoid conditions that allow for features that protrude from the connectors to catch on the anchor, giving a false sense
of being connected.
• Connectors should not be connected to each other.
• Connectors should not be connected directly to the webbing or to the rope lanyard or tie back, unless specically allowed by the
manufacturer.
• Connectors should not be connected to any object which does not allow the connector gate to close or lock. Anchor shapes that
allow roll out to occur should never be used for connection. If the anchor, to which the snap hook or carabiner is attached, is under
sized or irregular in shape, then this may allow for the gate of the connector to come in contact with the anchor, thereby causing the
connector to open up and possibly disengage from the anchor. This is known as roll out of the connector.
WARNING
Large throat opening snap hooks should not be connected to standard size D-rings or similar objects. The reason for this is if the hook or D-ring
twists or rotates, then this may result in a load on the gate of the connector. Large throat snap hooks are specically designed for use on xed
structure elements such as rebar or cross members. These are shaped in such a way that they cannot capture the gate of the hook.
IMPORTANT RESTRICTIONS WHILE MAKING CONNECTIONS
• A snap hook should not be connected into a loop or thimble of a wire rope, or attached to it in any way that may slack the wire rope.
• Do not make connections where the connector locking mechanism can come into contact with a structural member, or other such
equipment, as it may potentially unlock the connector and release the connection.
• To connect to a single or a pair of soft loops on a harness, a carabiner that can fully close and lock should only be used. Snap hooks
are not allowed for such connections.
• A carabiner may be connected to a loop or ring connector that is already occupied by a choker style connector. Snap hooks are not
allowed for such connections.
• Do not use connectors on an anchorage object as shown in gure A to G.
C.
B.
A.
F.
E.
D.
G.
If the connecting element to which a snap hook (shown) or carabiner attaches is undersized or irregular in shape, a situation
could occur where the connecting element applies a force to the gate of the snap hook or carabiner. This force may cause the
gate (of either a self-locking or a non-locking snap hook) to open, allowing the snap hook or carabiner to disengage from the
connecting point.
Small ring or other non-compatibly shaped element
2. The gate presses
against the
connecting Ring.
3. The gate opens
allowing the snap
hook to slip off.
1. Force is
applied to the snap
hook.
