Ÿ Two or more connectors should never be attached to a single D-ring.
and shapes of the connectors and the connecting elements do not allow their gate mechanisms to open inadvertently,
notwithstanding their orientation with each other. All hooks, carabiners, D-rings and other such connectors, must be
capable of supporting a min. force of 5000 lbs. (23 kN). All connectors must be compatible with all system components
like anchorages, etc. Never use equipment that is not compatible as this may cause the connectors to disengage
unintentionally. All connectors must be compatible in shape and size. As per ANSI Z359.12 and OSHA, only self-locking
snap hooks and carabiners may be used.
Ÿ A snap hook should not be connected into a loop or thimble of a wire rope, or attached to it in any way that may
slack the wire rope.
Ÿ Never attach a connector that could result in a load on its gate.
Ÿ Connectors should not be connected to each other.
Ÿ Connectors should not be connected directly to the webbing or to the rope lanyard or tie back, unless specifically
allowed by the manufacturer.
Ÿ Do not make connections where the connector locking mechanism can come into contact with a structural
member, or other such equipment, as it may potentially unlock the connector and release the connection.
While using KStrong snap hooks and carabiners, they should not be connected as below:
NEVER USE INAPPROPRIATE CONNECTIONS
WARNING
Ÿ Connectors should not be connected in a false engagement. It should be visually confirmed that the connector is
fully engaged to the anchor point. Avoid conditions that allow for features that protrude from the connectors to
catch on the anchor, giving a false sense of being connected.
Ensure that only self-locking snap hooks and carabiners are used with this equipment. All connections should be
compatible in size, shape and strength. The connectors used should be suitable to each application. Ensure that they
are fully closed and locked while in use.
Ÿ Connectors should not be connected to any object which does not allow the connector gate to close or lock.
Anchor shapes that allow roll out to occur should never be used for connection. If the anchor, to which the snap
hook or carabiner is attached, is undersized or irregular in shape, then this allows for the gate of the connector to
come in contact with the anchor, thereby causing the connector to open up and possibly disengage from the
anchor. This is known as roll out of the connector.
CONNECTIONS USING CONNECTORS
Large throat opening snap hooks should not be connected to standard size D-rings or similar objects. This is because if
the hook or D-ring twists or rotates, then this may result in a load on the gate of the connector. Large throat snap hooks
are specifically designed for use on fixed structure elements such as rebar or cross members. These are shaped in
such a way that they cannot capture the gate of the hook.
Ÿ Do not use connectors on an anchorage object as shown in figure G.
IMPORTANT RESTRICTIONS WHILE MAKING CONNECTIONS
Ÿ To connect to a single or a pair of soft loops on a harness, a carabiner that can fully close and lock should only be
used. Snap hooks are not allowed for such connections.
Ÿ A carabiner may be connected to a loop or ring connector that is already occupied by a choker style connector.
Snap hooks are not allowed for such connections.
C.
B.
A.
F.
E.
D.
G.
03
