KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VS-44HDxl 3G HD/SD-SDI 4x4 Matrix Switcher
6
Table 1: Front Panel VS-44HDxl 3G HD/SD-SDI 4x4 Matrix Switcher
#
Feature
Function
1 IR Receiver The red LED is illuminated when receiving signals from the Infra-red
remote control transmitter
2
POWER Switch
Illuminated switch for turning the unit ON or OFF
3
INPUT SELECTOR
(DUAL LINK) Buttons
Select the input to switch to the output (from 1 to 4).
In the dual-link mode, select input 1 or 2 to switch dual-link 1 or 2 to
the outputs
Press IN buttons 1, 2 and 3 simultaneously, to reset the machine to its
factory default values
1
(see section 6.6)
Use to set the resolution when switching genlocked video signals (see
section 6.7)
4 OUTPUT SELECTOR
(DUAL LINK) Buttons
Select the output to which the input is switched (from 1 to 4)
In the dual-link mode, select output DUAL LINK 1 or DUAL LINK 2 to
which the input is switched
5
STO (STORE) Button
Pressing STO followed by an INPUT / OUTPUT button stores the
current setting
2
6
TAKE
Button
Pressing
TAKE
toggles the mode between the
CONFIRM
mode
3
and
the AT ONCE mode (user confirmation per action is unnecessary).
When in CONFIRM mode, the TAKE button implements a pending
operation
4
7
RCL (RECALL) Button
Pressing the RCL button and the corresponding INPUT / OUTPUT
key recalls a setup from the non-volatile memory. After pressing the
same memory location the second time, the settings will take effect
8
ALL Button
Pressing ALL followed by an INPUT button, connects that input to all
outputs
5
9 OFF Button An OFF-OUT combination disconnects that output from the inputs; an
OFF-ALL combination disconnects all the outputs
Press and hold
6
to toggle between the 4x4 switcher mode and the
dual-link 2x2 switcher mode
10
LOCK Button
Disengages the front panel buttons
11
7-segment Display
Displays the selected input switched to the output (marked above
each input)
1 The 7-segmant display shows 1234 indicating that the operation mode is normal, and that the setups stored via the
INPUT/OUTPUT buttons have been erased
2 For example, press STO and then the Output button # 3 to store in Setup # 3
3 When in Confirm mode, the TAKE button illuminates
4 See section 7.2
5 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs
6 For more than 3 seconds
