KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating the VS-44HDxl
22
Actions no longer require user confirmation and the TAKE button no
longer illuminates.
7.2.2 Confirming a Switching Action
To confirm a switching action
1
(in CONFIRM mode where the TAKE button is
illuminated), do the following:
1. Press an OUT-IN combination.
The 7-segment Display blinks
2
.
2. Press the TAKE button to confirm the action.
The 7-segment Display no longer blinks. The TAKE button illuminates.
To confirm several actions (in CONFIRM mode), do the following:
1. Press each OUT-IN combination in sequence.
The 7-segment Display blinks.
2. Press the TAKE button to confirm all the actions.
The 7-segment Display no longer blinks. The TAKE button illuminates.
7.3 Storing/Recalling Input/Output Configurations
You can store and recall up to eight setup configurations using the four INPUT
buttons and the four OUTPUT buttons. The setup also includes the working
mode.
7.3.1 Storing an Input/Output Configuration
To store the current status in memory, do the following:
1. Set the working mode, see section 6.2.
2. Press the STO button.
The STO button illuminates.
3. Press one of the 8 INPUT / OUTPUT buttons (this will be the setup # in
which the current status is stored).
The selected INPUT / OUTPUT button illuminates in blue. The memory
stores the data at that reference.
To confirm the setup, press the INPUT/OUTPUT button again.
To cancel the setup, press the STO button once again
1 when operating the machine in the CONFIRM mode, the remote RS-232 control is disabled
2 The timeout lasts for 10 seconds
