Je bekijkt pagina 9 van 48
Figure 1: VS-42HDCP 4x2 DVI Matrix Switcher Front Panel
#
Feature
Function
1
IR Receiver and LED
IR remote control sensor. LED lights yellow when receiving an IR signal
2 INPUT SELECTOR
Buttons
TO OUTPUT 2 Press one of the 4 inputs to switch it to Output 2
3
TO OUTPUT 1
Press one of the 4 inputs to switch it to Output 1
4
OFF Button Output 1
Press to disconnect output 1 from the inputs
5
OFF Button Output 2
Press to disconnect output 2 from the inputs
6
EDID Button
Press to acquire the EDID (see Section 6.7)
7 STO Button Press to store a switching setting (see Section 6.3)
8
RCL Button
Press to recall a stored switching configuration from a preset (see Section 6.3)
9 LOCK Button Press and hold to toggle the locking/release of the front panel buttons.
Press to acquire the EDID (see Section 6.7)
6 VS-42HDCP – Overview
