VS-1616D - Connecting the VS-1616D 13
5 Connecting the VS-1616D
Always switch off the power to each device before connecting it to
your VS-1616D. After connecting your VS-1616D, connect its power
and then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
In the following example, only two inputs and
two outputs are connected.
The configuration of DVI input/output cards shown in Figure 4 is merely a sample
representation and different input / output cards may be mixed as required (for
limitations, see Section
5.1). Exactly the same principles apply to installations using
other card types.
To connect the VS-1616D, as illustrated in the example in Figure 4, do the
following:
1. Connect up to 16 DVI video sources (for example, computer graphics
sources).
2. Connect up to 16 DVI video acceptors, (for example, a plasma display and a
DVI LCD display).
3. If required, connect a PC or remote controller to the RS-232 port
(see Section 5.2) and/or the Ethernet port (see Section 5.3
).
4. Connect the power cord.
5. If necessary, review and set the system configuration using the Menu
(see Section 7
).
Given an input signal that is HDCP encoded, the VS-1616D outputs
a signal only if the output port to which it is switched supports HDCP.
