KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the VP-8x8TP 8x8 UXGA/Audio Matrix Switcher
8
#
Feature
Function
18 VIDEO INPUT 15-pin HD (F)
UXGA Connectors
Connect to the video sources (from 1 to 8)
19 OUT RJ-45 Connectors Connect to TP receivers (from 1 to 8), for example, TP-122
20 AUDIO INPUT 3.5mm Mini
Jacks
Connect to the unbalanced stereo audio sources (from 1 to 8)
21 FACTORY RESET Button Press and hold while powering up the unit to reset the audio,
switching, EDID and Ethernet settings to their factory default
values (see
Table 4)
IP Address: 192.168.1.39
Mask: 255.255.255.0
Gateway: 192.168.1.1
22 REMOTE IR Socket
1
Connect to an external IR receiver unit for controlling the
machine via an IR remote controller instead of using the front
panel IR receiver
2
23
Power Connector Socket Connect to the AC mains power
24 Power Connector Fuse AC mains power fuse
25 Power Switch Turns the AC mains power ON/OFF
26 PROG Button Push in for “Program” to upgrade to the latest Kramer firmware
via RS-232 (see Section
8), or release for “Normal” operation
(the factory default)
27 RS-232 Terminal Block Connect to a PC or remote controller (see Section 8)
28 RS-485 Terminal Block Connect to another RS-485-equiped device for control (see
Section
6.2)
29 RS-485 TERM DIP-switch
RS-485 bus termination
3
6.2.1
: ON to terminate with 120Ω, OFF for
no termination (see Section )
30 ETHERNET Connector Connect to a PC or other serial controller through the computer
network for control (see Section
8)
1 Covered by a cap. The 3.5mm mini connector at the end of the internal IR connection cable fits through this opening
2 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if the internal IR
connection cable has been installed)
3 The first and the last units on the RS-485 line should be terminated (ON). Other units should be unterminated (OFF)
