Table of ASCII Codes for Serial Communication (Protocol 3000)
40
14 Table of ASCII Codes for Serial Communication
(Protocol 3000)
Table 7 and Table 8 list the ASCII values to switch an input to an output for
a single VP-16x18AK machine. For more detailed information, see
Protocol 3000 (Section 16.2).
Table 7: VP-16x18AK Video Signal Codes for Protocol 3000
OUT 1
…
OUT 5
…
OUT Y
IN 1
#V 1>1 CR
…
#V 1>5 CR
…
#V 1>Y CR
…
…
…
IN 5
#V 5>1 CR
…
#V 5>5 CR
…
#V 5>Y CR
…
…
…
IN X
#V X>1 CR
…
#V X>5 CR
…
#V X>Y CR
Table 8: VP-16x18AK Audio Signal Codes for Protocol 3000
OUT 1
…
OUT 5
…
OUT Y
IN 1
#A 1>1 CR
…
#A 1>5 CR
…
#A 1>Y CR
…
…
…
IN 3
#A 5>1 CR
…
#A 5>5 CR
…
#A 5>Y CR
…
…
…
IN X
#A X>1 CR
…
#A X>5 CR
…
#A X>Y CR
Table 9 lists the codes that set the audio input gain. For more detailed
information, see Section 16.2.
Table 9: VP-16x18AK Audio Input Gain Codes
INPUT 1
…
INPUT 5
…
INPUT X*
Level
[Rel]
#AUD-LVL 1,1, -100CR
…
#AUD-LVL 1,5, -100CR
…
#AUD-LVL 1,X, -100CR
-100dB Mute
…
…
…
#AUD-LVL 1,1, -50CR
…
#AUD-LVL 1,5, -50CR
…
#AUD-LVL 1,X, -50CR
-50dB
…
…
…
#AUD-LVL 1,1, 0CR
…
#AUD-LVL 1,5, 0CR
…
#AUD-LVL 1,X, 0CR
0dB
…
…
…
#AUD-LVL 1,1, 20CR
…
#AUD-LVL 1,5, 20CR
…
#AUD-LVL 1,X, 20CR
+20dB (Max)
* Where X is the input number from 1 - 8. For example, for channel 7 and relative level -50dB, #AUD-LVL 1,7, -50CR
Table 10 lists the codes that set the audio output gain. For more detailed
information, see Section 16.2.
