Technical Specifications
37
37
11 Technical Specifications
Table 5 lists the technical specifications for the VP-16x18AK 16 x 18 PC
UXGA/Audio Router.
Table 5: Technical Specifications
1
of the VP-16x18AK
Note: All are measured on the local output unless specified otherwise
INPUTS:
16 XGA on 15-pin HD connectors (VGA through UXGA)
16 unbalanced stereo audio on 3.5mm mini jacks
OUTPUTS:
16 XGA on 15-pin HD connectors (VGA through UXGA)
16 balanced stereo audio on 5-pin terminal block connectors
2 TP on RJ-45 connectors
MAX. OUTPUT LEVEL:
VIDEO: 1.6Vpp
AUDIO: 9.6Vpp diff (12.8dBu)
BANDWIDTH (-3dB):
VIDEO: 400MHz
AUDIO: 20kHz
DIFF. GAIN:
0.1% maximum
DIFF. PHASE:
0.05 deg maximum
K-FACTOR:
Local output: 0.1%
S/N RATIO:
VIDEO: 62dB to 5MHz
AUDIO: 83dB
CROSSTALK (all hostile):
VIDEO: –35dB @ 100MHz
AUDIO: –68dB @1kHz
CONTROLS:
Volume: –105 to +30dB
Bass: –15 to 15dB
Treble: –20 to +20db
COUPLING:
VIDEO—
Local output: DC
CAT 5 output: AC
AUDIO—
Local output: input=AC, output=DC
CAT 5 output: input=AC, output=AC
AUDIO THD + NOISE:
Local output: 0.031% @1kHz
AUDIO 2nd HARMONIC:
Local output: 0.003% @1kHz
POWER
CONSUMPTION:
100-240V AC, 44VA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
19" x 9.5" x 3U (W, D, H) rack mountable
WEIGHT:
4.4kg (9.7lbs) approx
ACCESSORIES:
Power cord, rack “ears”, RC-IR3 Infrared Remote Control
OPTIONS:
External remote IR receiver cable
2
1
Specifications are subject to change without notice
2
P/N: C-A35M/IRR-50
