VP-1608 - Overview 3
3 Overview
The VP-1608 16x8 RGBHV/Balanced Audio Matrix is a true matrix switcher,
routing any input to any or all outputs. The VP-1608 includes 16 input and 8 output
selector buttons.
The unit features:
• A bandwidth of 400MHz (fully loaded) for RGB signals
• A unique vertical and horizontal sync-pulse solution
• Audio-follow-video or audio breakaway option (to switch audio independently
from video)
• 15 preset memory locations for quick access to common configurations
• A “TAKE” button for precise switch control, letting you place multiple switches
in a queue, and then activate them, with one touch of this button or a single
serial command
• A delayed switching mode (ranging from 0 to 3.5sec in increments of
0.5sec), for clean transitions when switching between non-genlocked
sources
Control the VP-1608 using the front panel buttons, or remotely via:
• RS-485 or RS-232 serial commands—that also support audio gain
adjustments for each input and output—transmitted by a touch screen
system, PC, or other serial controller
• The Kramer RC-IR3 Infrared Remote Control Transmitter
The VP-1608 is dependable, rugged and fits into three vertical spaces (3U) of a
standard 19" rack.
3.1 Defining the VP-1608 16x8 RGBHV/Balanced Audio
Matrix
Figure 1 and Figure 2 define the front and rear panels of the VP-1608. Figure 3
defines the switches on the underside.
