Kramer VP-1608 handleiding
Handleiding
Je bekijkt pagina 3 van 46
VP-1608 – Contents i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
3 Overview 3
3.1 Defining the VP-1608 16x8 RGBHV/Balanced Audio Matrix 3
4 Installing in a Rack 8
5 Connecting a Single VP-1608 9
5.1 Connecting a Balanced/Unbalanced Stereo Audio Input/Output 11
5.2 Connecting to the VP-1608 via RS-232 11
5.3 Connecting a PC or Controller to the RS-485 Port 11
5.4 Setting the MACHINE # DIP-Switches 12
5.5 Setting the DELAY DIP-Switches 13
6 Connecting Multiple VP-1608 Units 14
6.1 Connecting via a PC or Serial Controller 14
6.2 Connecting via an RS-485 Controller 15
7 Operating Your VP-1608 16x8 RGBHV/Balanced Audio Matrix 17
7.1 Using the Audio-Follow-Video or Breakaway Option 17
7.2 Switching OUT-IN Combinations 18
7.3 Confirming Settings 19
7.4 Storing/Recalling Input/Output Configurations 20
7.5 Adjusting the Audio Gain Control 22
7.6 Locking and Unlocking the Front Panel 22
7.7 Resetting the VP-1608 16x8 RGBHV/Balanced Audio Matrix 22
7.8 Displaying Unit Characteristics 23
8 Flash Memory Upgrade 24
8.1 Downloading from the Internet 24
8.2 Connecting the PC to the RS-232 Port 24
8.3 Upgrading the Firmware 25
9 Technical Specifications 30
10 Table of Hex Codes for Serial Communication 31
11 Hex Tables for Audio Input/Output Gain Control 33
11.1 Hex Tables for Audio Input Gain Control 33
11.2 Hex Tables for Audio Output Gain Control 35
12 Kramer Protocol 2000 37
Bekijk gratis de handleiding van Kramer VP-1608, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | Kramer |
| Model | VP-1608 |
| Categorie | Niet gecategoriseerd |
| Taal | Nederlands |
| Grootte | 7161 MB |
Caratteristiche Prodotto
| Kleur van het product | Black, Grey |
| Gewicht | 5500 g |
| AC-adapterfrequentie | 50/60 Hz |
| RS-232 port | 1 |
| BNC output ports | 24 |
