Kramer Electronics Ltd.
VIA Campus2/ VIA Campus2PLUS – Defining VIA Campus2/ VIA Campus2PLUS
9
Defining VIA Campus2/ VIA
Campus2PLUS
This section defines VIA Campus2/ VIA Campus2PLUS.
Figure 4: VIA Campus2/ VIA Campus2PLUS Front
#
Feature
Function
Power Button
For turning the machine on and off. Button lights when the unit is turned
on.
USB 2.0 Connector
For connecting a USB device.
Figure 5: VIA Campus2/ VIA Campus2PLUS Back
#
Feature
Function
DC IN 19V Connector
Connects to the 19V DC power adapter.
Wi-Fi Antenna Port (1 of 2)
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
HDMI OUT Connector
Connect to an HDMI display.
HDMI IN Connector
Connect to an HDMI source (for example, a laptop) – only available for
Campus2PLUS
DP OUT Connector
Connect to a DisplayPort display.
USB 2.0 Connectors
Connect to up to 2 USB devices.
LAN RJ-45 Connector
Connect a Local Area Network (LAN) cable.
USB 3.0 Connectors
Connect to up to 2 USB devices.
AUDIO MIC IN 3.5mm Jack
Connect to a microphone.
Wi-Fi Antenna Port (2 of 2)
Connect one of the Wi-Fi antennas for collaborating via the built-in Wi-Fi.
AUDIO LINE OUT 3.5mm Jack
Connect to an unbalanced stereo audio acceptor.
REMOTE 2-pin Terminal Block
Connect to a toggle switch to remotely turn the device on and off.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
