Communication Protocol
17
Byte 2 Command Description Byte 3 (parameter value)
GLOBAL
20 OUTPUT FORMAT 0 - YUV
1 - RGB
2 - RGBS
21 OUTPUT_STANDARD 0 - PAL B
1 - PAL N
2 - PAL M
3 - NT 3
4 - NT 4
5 - SEC
22 GENLOCK 0 - OFF
1 - ON
23 PANEL_LOCK 0 - OFF
1 – ON
24 SCH -100 - +100
24 DELAY -100 - +100
26 FREEZE 0 - OFF
1 - ON
27 PROGRAM 0 - 15 (read only)
28 GENLOCK_STAT (Read only)
0 – No GENLOCK
1 – GENLOCK
Byte 4 is the machine address: can be 98 or 99 (in HEX).
First byte = I
Second byte=D
Third byte=E
MACHINE TO PC:
MACHINE POWER-UP
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
PRESS OF "RECALL"
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
PRESS OF "STORE"
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
CHANGE "OUTPUT_STANDARD"
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
CHANGING OTHER KEYS
PC <- I = 33;D = PARAMETER NUMBER; E = PARAMETER <- MACHINE (PARAMETER WRITE)
PC TO MACHINE:
RESET VIDEO
POWER-UP(PSEUDO)
PC -> I = 0;D = 0;E = 0 -> MACHINE
PC <- I = 0;D = 0;E = 0 <- MACHINE
DEFAULT
PC -> I = 0;D = 1;E = 0 -> MACHINE
WRITE EEPROM ALL PARAMETERS - DEFAULT (ALL PROGRAMS),RELOAD (RESTART)
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
PARAMETER READ
PC -> I = 32;D = PARAMETER NUMBER;E = 0 -> MACHINE
PC <- I = 32;D = PARAMETER NUMBER;E = PARAMETER <- PARAMETER
PARAMETER WRITE
PC -> I = 33;D = PARAMETER NUMBER;E = PARAMETER -> MACHINE
PC -< I = 33;D = PARAMETER NUMBER;E = PARAMETER <- MACHINE
WRITE OUTPUT_STANDARD
PC -> I = 33;D = 21;E = PARAMETER -> MACHINE MACHINE RELOAD (RESTART)
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE (RECALL)
RECALL
PC -> I = 34;D = 0;E = PROGRAMM NUMBER -> MACHINE
PC <- I = 34;D = 0;E = PROGRAMM NUMBER <- MACHINE
PROGRAMM NUMBER - 0 = PROGRAMM 1
PROGRAMM NUMBER - 1 = PROGRAMM 2
PROGRAMM NUMBER - 15 = PROGRAMM 16
