Kramer Electronics Ltd.
PT-12 – Configuring PT-12
7
Configuring PT-12
You can configure PT-12 in the following ways:
• DIP-Switches (see Configuring Using DIP-Switches on page 7).
• EDID Designer Software – to modify the EDID (see Modifying EDID with EDID
Designer on page 9).
• Protocol 3000 API (see Protocol 3000 Commands on page 15).
Configuring Using DIP-Switches
PT-12 enables you to control EDID lock, define signal parameters, configure display
auto power and display auto sleep, and upgrade the device firmware using the DIP-
switches on the back panel.
The following table describes the PT-12 DIP-switches.
By default, all switches are in the OFF (up) position.
All changes in the DIP-switch settings take effect on-the-fly, without the need for a
power cycle.
#
Feature
Description
1
EDID Lock
OFF (up) – Lock the current EDID so that changes on the output do not result
in changes to the EDID.
ON (down) – EDID is passed-through and acquired automatically.
2
Deep Color
OFF (up) – Limit color depth to 8 bits per color.
ON (down) – Pass-through color depth parameters.
3
Audio Pass-through
OFF (up) – Audio transmission is limited to 2-channel LPCM only.
ON (down) – Audio transmission is passed-through.
Audio pass-through setup takes effect only when DIP-switch 1 is OFF (EDID
locked), otherwise, it is ignored.
4
HDCP Operation
OFF (up) – HDCP is disabled, giving the appearance that HDCP is not
supported.
ON (down) – HDCP is enabled, giving the appearance of an HDCP authorized
device to allow unsecured content display by all market-available computer
sources.
5
Display Auto Power
OFF (up) – Display auto power is enabled.
ON (down) – Display auto power is disabled.
6, 7
Display Auto Sleep
Enable/disable auto delay (before 5V output cut-off) of the connected display
when no active input signal is detected.
DIP 6
DIP 7
Delay before Auto Sleep (before 5V output cut-off)
OFF
OFF
Auto Sleep is disabled
ON
OFF
5s
OFF
ON
1m
ON
ON
15m
8
CPU FW Upgrade
OFF (up) – Normal operation mode.
ON (down) – CPU firmware upgrade mode.
When set to ON the device is inactive.
