Kramer Electronics Ltd.
MTX3-88-HSA – Using Embedded Web Pages
26
3. If required, perform one of the following:
Click (on output port) to mute the video output signal. indication appears.
Click (on output port) to mute the audio output signal. indication appears.
Click (on output port) to turn Pattern set on. indication appears.
The selected inputs are switched to the selected outputs.
Adjusting Input and Output Port Settings
1. In the navigation list select AV Settings>Video tab.
To adjust input port settings (see Configuring Video Input Settings on Page 30).
To adjust output port settings (see Configuring Video Output Settings on page 31).
Figure 16: Input/Output Port Settings Page
Saving a Preset
To save a specific matrix routing scheme and configuration:
1. On the bottom of the AV grid, click Save as Preset.
Figure 17: Save Selected Routing & Configuration as a Preset
2. Enter the following data:
• Select a preset number to save (8 in total).
3. Click:
• Save Preset to save the selected routing and configuration to the selected preset
