Kramer Electronics Ltd.
MTX3-16-M, MTX3-34-M – Introduction
4
Warning:
• Use only the power cord that is supplied with the unit.
• When connecting the device to power, only use a grounded socket.
• Disconnect the power and unplug the unit from the wall before installing.
• Do not open the unit. High voltages can cause electrical shock! Servicing by qualified
personnel only.
• To ensure continuous risk protection, replace fuses only according to the rating
specified on the product label which is located on the bottom of the unit.
• All Kramer Laser Transceivers used in the matrices are:
• UL and CDRH certified.
• Emitting radiation of CDRH “Class 1” (when installed without connecting a fiber optic cable).
• Complying with IEC 62368-1 and IEC 60825-1 and –2.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment
.
Overview
MTX3-16-M and MTX3-34-M are intelligent and high-performance modular matrices for
switching and distribution of multi-format audio-visual signals. Their chassis includes a CTRL
central control card with secured LAN connectivity for remote management and control. All
matrices are flexibly populated by any matrix cards from the same compatible family of multi-
format matrix cards.
MTX3-16-M includes eight horizontal card slots and MTX3-34-M includes seventeen vertical
card slots for flexible insertion of modular matrix cards, accommodating matrix cards with
quad or dual ports of either input or output multi-format signals.
Most of the information included in this user manual is relevant to
both MTX3-16-M and to
MTX3
-34-M.
Unless specified otherwise,
MTX3-16-M is used throughout this user manual to refer to both
devices.
Exceptional Quality
• High Resolution Audio-Visual Experience – MTX3-16-M is a professional, 8K-ready
matrix for switching multi-format AV signals. The modular matrix cards support 4K60
4:4:4 multi-format AV signal distribution and the backplane router is ready for 8K audio-
visual signal switching, enabling future upgrades to 8K-capable matrix cards.
