Kramer Electronics Ltd.
AW-6P – Installation Guide
6
High Impedance Installation (70V / 100V)
Description:
This method uses a transformer to distribute audio over long distances using thin speaker
cables. Ideal for large areas or multi-speaker installations such as retail stores, restaurants,
schools, or outdoor spaces.
Key Features:
• Supports multiple speakers on a single amplifier channel, installed in parallel.
• Long cable runs (up to hundreds of meters) without significant loss.
Note:
In high impedance mode the AW-6P supports the following power ratings:
o at 100V – 30W / 15W / 7.5W
o at 70V – 30W / 15W / 7.5W / 3.8W
When to Choose a Low Impedance 8Ω Setup
• When Sound Quality Is Top Priority
• 8Ω setups deliver direct, full-bandwidth signal from the amplifier to the speaker -
no transformer losses.
• Ideal for:
o Boardrooms, conference rooms, auditoriums & lecture halls
o Music-focused zones (bars, studios, luxury retail)
• When You Have a Small Speaker Count
• A typical low-impedance amp channel supports 1 to 2 speakers per channel,
maybe 4 if impedance allows.
• Perfect if:
o You’re wiring 1–4 speakers to a single amplifier channel.
o You don’t need multiple zones from one line.
• When Cable Runs Are Short
• Ideal for speaker cables under 30–50 meters (100-164 ft)
• No need to compensate for long-distance power loss with transformers.
• When You Want to Use Subwoofers or High-Power Speakers
• Low-impedance amps can directly deliver the necessary wattage.
• When You Need High SPL or Full-Range Performance
• Transformer-based 70V/100V systems often cut low frequencies to protect
transformers and reduce core size.
• For full-range systems where bass and clarity matter - 8Ω wins.
