Kramer Electronics Ltd.
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX – Operating ASPEN-32UFX, ASPEN-1616UX, VS-8UFX
24
Take Mode Switching
To execute multiple switching events, simultaneously:
1. Press the TAKE Button .
The TAKE Button flashes and the panel enters Take Mode.
2. Press a green output PORT Button and a blue input PORT Buttons .
The switching event appears on the LCD display.
3. Press additional input/output pairs.
The switching events appear on the LCD display.
4. Press the TAKE Button .
All of the selected switching events are executed.
Loading Saved Configurations – Front Panel
VS 8UFX front panel buttons enable you to load preset input/output definitions and switching
configurations.
To save a configuration, see Saving Configuration – Front Panel on page 20.
To load a saved configuration:
1. Click the LOAD Button .
The LOAD Button flashes and PORTS Buttons lights go off.
2. Click the PORTS Button that corresponds to the preset number under which the
configuration is saved.
The selected PORTS Button flashes red and the preset configuration appears on the
LCD display.
3. Click the TAKE Button .
The configuration is loaded and the PORTS Buttons light normally.
