Kramer Electronics Ltd.
860 – Overview
3
Overview
The 860 HDMI 18G (6G per graphic channel) Signal Generator & Analyzer is an advanced
and handy tool for generating, testing and verifying the signal path within your (up to)
4K@60Hz (4:4:4) HDMI 2.0 / HDCP 2.2 ecosystem. With 88 built-in resolutions, 55 test
patterns and over a dozen types of A/V analysis functions, this unit provides an enormous
range of testing options. HDMI data packet, EDID and HDCP analysis is supported along with
EDID upload and emulation. Additionally the Status and Control Data Channel (SCDC) can be
monitored, allowing HDMI 18G signal detection and analysis. Up to 8 channels of LPCM
audio test tones can be generated with a wide range of frequencies.
The unit also supports the ability to upload up to 2 user-generated graphic files which can be
used as additional test patterns. The use of multi-function and multi-color backlit buttons
allows for easy operation of the unit’s wide variety of functions and a clear OLED display
provides a way to quickly view the current signal status information. In addition to the front
panel buttons, the unit can also be controlled via RS-232, Telnet and IR providing a complete
range of control options.
The 860 features:
• Resolution support up to 4K@60Hz (4:4:4)
• HDMI 2.0, HDCP 2.2, HDCP 1.4 and DVI 1.0 compliance
• Analysis of source and sink data paths up to 18G HDMI signals (6G per graphic
channel)
• Analysis of HDMI data packets
• Analysis and control of HDCP v1.4 and v2.2
• Analysis and emulation of EDID data, including SCDC
• Analysis of input audio signals
• HDR bypass and analysis support
• HDMI timing generation up to 4096×2160@60Hz 4:4:4, 8-bit
• Heavy duty, waterproof, padded protective case
• HDMI and VGA signal output generation:
VGA output supports 350p, 480p, 576p, 720p, 1080i, 1080p, 640×480, 800×600,
1024×768, 1280×1024, 1366×768, 1400×1050, 1440×900, 1600×900 (Reduced
Blanking; RB), 1600×1200, 1680×1050, 1920×1200 (RB), 2048×1080p
HDMI output supports 350p, 480p, 576p, 720p, 1080i, 1080p, 640×480, 800×600,
1024×768, 1280×1024, 1366×768, 1400×1050, 1440×900, 1600×900 (RB), 1600×1200,
1680×1050, 1920×1200 (RB), 3G4K, 6G4K
• 2 custom user test pattern resolutions: 640×480 & 1920×1080
• External stereo audio input and output
• LPCM sinewave audio generation – up to 8 channels
• Front-panel, RS-232, Telnet, and IR Remote controls
