39
© 2021 KOSTAL Solar Electric GmbH
Installation
Cable specification
n
AC grid connection
Select the conductor cross-section according to the
rated output current and the type of routing.
Take into account necessary reduction factors for
ambient temperature and accumulation (when laying
several cables without spacing).
Example: Ambient temperature 40 °C: Reduction
factor 0.87 (according to DIN VDE 0100-520 /
HD60364-5-52).
Cable type Cable length
Copper conductor
4-wire (3L/PE without N) or
5-wire (3L/N/PE)
max. 200m
PIKO CI
Wire
cross-section
Cable diameter
30 10 - 25 mm² 24 - 32 mm
50 / 60 30 - 50 mm² 25 - 40 mm
n
Additional PE connection
PIKO CI Wire cross-section
30 ≥ 16 mm²
50 / 60 ≥ 35 mm²
n
DC PV connections
Cable type
Wire
cross-section
Cable diameter
Solar cable
e.g. PV1-F
4 - 6 mm² 6 - 8 mm
INFO
For outdoor installation, use UV-re-
sistant cable. Alternatively, lay the
cable protected from solar radiation.
