SWING function

1. Press the SWING button to activate the louver,

o Press to activate the horizontal flaps to swing from up to down, Press

again to stop the swing movement at the current angle.

o Press to active the vertical deflectors to swing from left to right. Press

again to stop the swing movement at the current angle.

2. If the vertical deflectors are positioned and placed under the flaps, they allow the

air flow to move rightward or leftward.

3. For some inverter heating models, pressing horizontal SWING and vertical SWING

buttons at the same time will activate the Self-Clean function.

This adjustment must be done while the appliance is switched off.

Never position Flaps manually, the delicate mechanism may be seriously damaged.

Never put fingers, sticks or other objects into the air inlet or outlet vents. Such

accidental contact with live parts might cause unforeseeable damage or injury.

TURBO function

To activate turbo function, press the button and will appear on the display.

Press again to cancel this function. In COOL/ HEAT mode, when you select TURBO

feature, the appliance will quickly COOL or quickly HEAT and operate at the highest fan

speed.

MUTE function

1. Press button to active this function. The icon will appear on the remote

display. Pressing the button gain will deactivate this function.

2. When the MUTE function runs, the remote controller will display the auto fan speed

and the indoor unit will operate at the lowest fan speed.

3. If FAN, TURBO or SLEEP buttons are pressed, the MUTE function will be cancelled.

MUTE function cannot be activated under dry mode.
