Step 5: Connecting Refrigerant Pipe

1. Unscrews the valve cover, grasp and press it down gently to remove it (if the valve

cover is applicable).

2. Remove the protective caps from the end of the valves.

3. Remove the plastic cover in the pipe ports and check whether there is any dirt or

debris on the port of the connecting pipe and make ensure the port is clean.

4. After aligning the centre, rotate the flare nut of the connecting pipe to tighten the

nut by hand as firmly as possible.

5. Using a spanner, hold the body of the valve and use a torque wrench to tighten the

flare nut (refer to the torque requirements table).

Take down the valve cover

flare nuts

connection pipes
