Step 2: Install Mounting Plate

1. Take the mounting plate from the rear of the indoor unit.

2. Ensure to meet the minimum installation dimension requirements as step 1, according

to the size of the mounting plate, determine the position and stick the mounting plate

close to the wall.

3. Adjust the mounting plate to a horizontal state with a spirit level, then mark out the

screw hole positions on the wall.

4. Put down the mounting plate and drill holes in the marked positions using a drill.

5. Insert expansion rubber plugs into the holes, then hang the mounting plate and fix it

with screws.

Mounting plate

Spirit level

Reference screw positions

Note:

• Make sure the mounting plate is firm enough and flat against the wall after

installation.

• This figure shown may be different from the actual object, please take the latter

as the standard.
