27
Step 6: Vacuum Pumping
1. Use a spanner to remove the protective caps from the service port, low-pressure
valve, and high-pressure valve of the outdoor unit.
2. Connect the pressure hose of the manifold gauge to the service port on the
outdoor unit's low-pressure valve.
3. Connect the charge hose from the manifold gauge to the vacuum pump.
4. Open the low-pressure valve of the manifold gauge and close the high-pressure
valve.
5. Turn on the vacuum pump to evacuate the system.
6. The vacuum time should be at least 15 minutes, or until the compound gauge
indicates -0.1 MPa (-76 cm Hg).
7. Close the low-pressure valve of the manifold gauge and turn off the vacuum
pump.
8. Hold the pressure for 5 minutes, ensuring that the compound gauge pointer does
not exceed 0.005 MPa.
9. Open the low-pressure valve anti-clockwise for 1/4 turn with a hexagonal spanner
to allow a small amount of refrigerant to fill the system. Close the low-pressure
valve after 5 seconds and quickly remove the pressure hose.
10. Check all indoor and outdoor joints for leaks using soapy water or a leak detector.
11. Fully open the low-pressure valve and high-pressure valve of the outdoor unit with
a hexagonal spanner.
12. Reinstall the protective caps on the service port, low-pressure valve, and high-
pressure valve of the outdoor unit.
13. Reinstall the valve cover.
Compound gauge
Low pressure valve
S
ervice port
Hi
gh pressure valve
Valve protective caps
Pressu
re hose
Vacuum pump
C
harge ho
se
Low pressure valve
High press
ure valve
Pressure gauge
M
anifold gauge
