17
Step 2: Install the Mounting Plate
1. Take the mounting plate from the back of the indoor unit.
2. Ensure you meet the minimum installation dimension requirements as described in
step 1. Based on the size of the mounting plate, determine the position and stick
the mounting plate close to the wall.
3. Adjust the mounting plate to a horizontal position using a spirit level, then mark
the screw hole positions on the wall.
4. Remove the mounting plate and drill holes at the marked positions with a drill.
5. Insert wall anchors into the holes, then hang the mounting plate and secure it with
screws.
70mm (∅2.8”)
Notes:
• Ensure the mounting plate is firm enough and flat against the wall after
installation.
• The figure shown may differ from the actual appliance. Refer to the actual
appliance as the standard.
