49
English
• Disconnect the product from the power
supply.
• Place the product with the lower drain
outlet above a suitable container or a drain.
• Remove the cover of the lower drain outlet.
• Attach the cover of the outlet again, when
all water is drained.
• Connect the plug to a suitable socket.
• The product is ready to be switched on.
Under some circumstances (e. g. high humidity)
the self-evaporation system may not be
sucient to handle the water and excessive
water is collected in the internal tank, which
must be drained as described above when full.
Activation and deactivation of WiFi
Note:
The standard setting of the WLAN function
is deactivated at the factory.
Fig.
12
Press and hold the SWING button for
about 3 seconds to activate the WiFi
function. AP appears on the display.
To deactivate the WiFi function, press
and hold the SWING button for about
3seconds.
Installation and use of WLAN/IoT functions
For activation, installation and use of WLAN
/ IoT functions, please refer to the separate
instructions with the corresponding title.
Cleaning & care
Switch the product into Standby and unplug in
order to disconnect from the mains.
Note:
Clean the product every two weeks. Clean
the outer surfaces of the product with a
damp cloth soaked in neutral detergent. Dry
it with a lint-free cloth. Do not use chemical,
alkaline, abrasive or other aggressive
detergents as they might be harmful to the
surfaces.
Preprogramming a function
By pushing the SHORTCUT button any
function and temperature can be saved and
recalled.
• Choose your desired function e.g. using
the MODE, TEMP
/ + or / – and FAN
buttons, etc.
• Press and hold the SHORTCUT button until
the display flashes once to save the setting.
• The preset setting can be recalled anytime
and from any mode by simply pushing the
SHORTCUT button.
Fig.
11
Water drainage
Water is only collected during automatic AUTO,
cooling COOL and dehumidifying mode DRY.
During dehumidifying mode DRY water
is drained immediately through the upper
drain outlet and the drainage hose must be
continuously connected.
The water must be drained through the hose
into a suitable container or nearby drain using
the upper drain outlet.
Warning
Danger of flooding! Do not leave the
product unattended when draining to an
external container! Empty the container
frequently to avoid spilling over and water
damage.
Note:
If the water is not drained to an external
container and the upper drain outlet is closed
during automatic AUTO or cooling mode
COOL water is collected in an internal tank,
which must be drained when full. In this case
the product will emit an audible signal, while
the display on the control panel is showing
the protection code P1. The cooling process
will stop until the water is drained and the
product restarted, while the fan remains
running.
IM_KAC9022W-WLAN_211125_V05_HR.indb 49 25/11/2021 11:24 AM
