48
English
Size - A5
Fig.
10
Setting the timer
The timer switches the product on or standby
when a user-defined time has elapsed. When
switching on, the last mode and setting will be
used.
The set durations will be counted down
immediately.
• Press the timer program button TIMER at
the product or the specific TIME ON/OFF
button at the remote control to enter the
timer setting for either the auto-on or auto-
o timer. The respective indicator for each
setting will light up.
• Press the + / – buttons or the specific TIME
ON/OFF button at the remote control as
often as necessary to set a time from 0.5 to
24 hours.
• The setting will be saved in the product
after 5 seconds without input.
Note:
The indicator lights are on when the timer is
activated.
Examples:
• To have the product switch into standby
after 1 hour and on again after another 1½
hours, set the auto-o time to 1.0 h and the
auto-on time to 2.5 h during operation.
• To have the product switched on after 8
hours and standby after another 8 hours,
set the auto-on time to 8.0 h and the auto-
o time to 16.0 h while in standby.
Note:
• The adjusting increments are 0.5 hours up
to 10 hours, then 1 hour up to 24 hours.
• The respective indicator will be lit, when a
time is set.
• Switching the product on or into standby
manually will cancel the timer setting.
• The timer settings will be lost once the
respective actions were conducted and
the time needs to be set again. The timer
setting will be lost in case an error occurs
(see protection and error codes).
The product is intended for the following
ambient temperatures:
Mode Temperature
AUTO
auto
17 °C (62 °F) - 35 °C (95 °F)
COOL
17 °C (62 °F) - 35 °C (95 °F)
DRY
13 °C (55 °F) - 35 °C (95 °F)
Warning
Any other conditions and locations as the
mentioned above may result in reduced
performance of the product, injuries and
damage to property.
Fig.
7
Setting the temperature
Press the / + or / – button to select a
temperature between 17 °C to 30 °C.
Fig.
8
Setting the fan speed
• Press the fan speed button FAN to toggle
between the speed settings.
• The respective indicator on the control panel
and the remote control show the current
setting.
Note:
There is no indicator for the auto speed
setting.
Fig.
9
Air outlet adjustment
The air outlet can be adjusted in any mode to
fit required needs.
• Press the oscillation button SWING
repetitively to turn oscillation on or o. The
air flap will oscillate continuously.
• To stop the air flap at a desired position
press button SWING again.
Note:
Do not move, open or shut the air flap
manually.
IM_KAC9022W-WLAN_211125_V05_HR.indb 48 25/11/2021 11:24 AM
