52
English
Size - A5
Setting the timer
The timer switches the product on or into
standby when a user-defined time has elapsed.
When switching it on, the last mode and
setting will be used.
• Press the timer program button in on or
standby state to enter the timer setting for
either the auto-on or auto-o timer. The
respective indicator for each setting will
light up.
Product panel
• Press the button as often as necessary
to set a time from 1 to 24 hours (in 1 hour
interval).
• The setting will be saved in the product
after 5 seconds without input.
Remote control
Switch-on time
• Switch on the product and set the desired
temperature. Turn o the product.
• Press the timer button to activate the
timer setting. The symbol flashes on the
remote control display (10x).
• Press the +/- button on the remote
control as often as necessary to set a time
between 0.5 and 24 hours.
• The setting is saved by pressing the
timer button. The symbol is displayed
continuously. After the set time has elapsed,
the product switches on.
Switch-o time
• Press the timer button while the product is
switched on. The symbol flashes on the
remote control display (10x).
• Press the +/- button on the remote
control as often as necessary to set a time
between 0.5 and 24 hours.
• The setting is saved by pressing the
timer button. The symbol is displayed
continuously. After the set time has elapsed,
the product switches o.
The product is intended for the following
ambient temperatures:
Mode Temperature
COOL 18 °C (64 °F) - 35 °C (95 °F)
DRY 18 °C (64 °F) - 35 °C (95 °F)
Warning
Any other conditions and locations as the
ones mentioned above may result in reduced
performance of the product, injuries and
damage to property.
Fig.
7
Setting the temperature
Press the / + or / – button to select a
temperature between 18 °C to 32 °C.
Fig.
8
Setting the fan speed
• Press the fan speed button / to toggle
between the speed settings.
• The respective indicator on the control panel
and the remote control show the current
setting.
Fig.
9
Air outlet adjustment
The air outlet can be adjusted in any mode to
fit the required needs.
• Press the oscillation button repetitively
to turn oscillation on or o. The air flap will
oscillate continuously.
• To stop the air flap at a desired position
press button again.
Note:
Do not move, open or shut the air flap
manually.
