23
EN
• The angle of the bend of the exhaust air pipe should not be less than 120°.
Align the pipe horizontally. Alternatively, the pipe should go up from the
starting point and be led to an outer wall.
• After installation, make sure that the cooker hood is horizontal in order to
prevent grease from collecting on one side.
• Make sure that the exhaust duct selected for installation complies with the
relevant standards and is re resistant.
Installation of the sloping hood
Drill 3 x 8 mm holes for the wall bracket. Fix the wall bracket to the wall with
the supplied dowels and screws.
Lift the extractor hood and
hang it on the wall bracket.
Borehole
Dowel
Holder
Screws
(4 mm x 30 mm)
