48
EN
CONVERSION OF THE APPLIANCE (INSTALLER)
Changing the injectors
• The burners can be adapted to different types of gas by simply installing
the injectors suitable for the gas you want to use. The “kit injectors” can be
supplied together with the appliance or purchased.
• To do this, rst remove the burner cups and with a socket spanner, unscrew
injectors using proper tool and replace them with injectors corresponding to
the new adjustment gas type. Always tightly lock the injector in place, without
adding any material on the injector’s threads: It is forbidden!
• To help the installer, there is a table in the “Technical Data” section giving
nominal heat input, injector diameter and operating pressures of the different
types of gas. For best comprehension, each injector is marked on its body with
proper diameter.
• After the injectors have been changed, the technician must adjust the
burners as described in the previous paragraphs. Seal any adjustment or
preadjustment parts.
Important note: After the conversion, substitute the adjustment sticker data
plate put on the bottom of the appliance with the new one, corresponding to
the new gas adjustment. The sticker is included in the “kit injectors”.
MAINTENANCE (INSTALLER)
Note: Prior to any maintenance work or before changing parts, disconnect the
appliance from the gas and electricity power sources.
Replacing components
• To access the terminal board and the power cable, it is necessary to remove
the hob from the cabinet by unscrewing the relative xing screws (V) (see
gure 7).
• If the power cord needs to be replaced, contact customer service or a similarly
qualied person as it is necessary to use special utensils. The technician will
have to connect a cable with a suitable cross section keeping the earth wire
longer than the phase wires.
• To replace other gas and electrical components, that are lodged inside the
hob, it is enough to remove the work top unscrewing the xing screws of the
burners.
• Replace the seal each time you change a tap in order to guarantee a perfect
tightness between body and rail.
