4.2. Channels
Modbus Register type Description Possibilities
2000 Enumeration Unit selection of the channel 1 According to probe and board
2010 Enumeration Selection of probe or board Probe 1 / Probe 2 / Board / Deactivated
2100 Enumeration Unit selection of the channel 2 According to probe and board
2110 Enumeration Selection of probe or board Probe 1 / Probe 2 / Board / Deactivated
2200 Enumeration Unit selection of the channel 3 According to probe and board
2210 Enumeration Selection of probe or board Probe 1 / Probe 2 / Board / Deactivated
2300 Enumeration Unit selection of the channel 4 According to probe and board
2310 Enumeration Selection of probe or board Probe 1 / Probe 2 / Board / Deactivated
4.3. Outputs
Modbus Register
type
Description Possibilities
3000 Enumeration Analogue output selection of the channel 1 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3100 Enumeration Analogue output selection of the channel 2 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3200 Enumeration Analogue output selection of the channel 3 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3300 Enumeration Analogue output selection of the channel 4 4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3010 Enumeration Channel 1 diagnostic: generation of a
current or a voltage
Generation according to the output signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
3110 Enumeration Channel 2 diagnostic: generation of a
current or a voltage
Generation according to the output signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
3210 Enumeration Channel 3 diagnostic: generation of a
current or a voltage
Generation according to the output signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
3310 Enumeration Channel 4 diagnostic: generation of a
current or a voltage
Generation according to the output signal
0-10 V 0-5 V 0-20 mA 4-20 mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10 mA 12 mA
10 V 5 V 20 mA 20 mA
26
Description of function and Modbus connections
