52" Pillar LED | 5
MOUNTING OPTIONS
If there isn’t an existing UL (cUL for Canadian Installation ) listed
mounting box, then read the following instructions. Disconnect the
power by removing fuses or turning o circuit breakers.
Secure the outlet box directly to the building structure. Use
appropriate fasteners and building materials. The outlet box and its
support must be able to fully support the full weight of the fan (up to
50 lbs). Do not use plastic outlet boxes.
Figure 1, 2 and 3 are examples of dierent ways to mount the outlet
box.
NOTE: NOTE: If you are installing the ceiling fan on a sloped (vaulted) ceiling,
you may need a longer downrod to maintain proper clearance
between the tip of the blade and the ceiling. A minimum clearance of
12” is suggested for optimal operation.
NOTE: NOTE: Depending on the location you have selected for installation,
you may need to purchase and install a “Joist Hanger” for the support
of the outlet box. Make sure the joist hanger you purchase has been
designed for use with ceiling fans. (Fig.4)
Outlet box
ANGLED CEILING
MAXIMUM 20° ANGLE
Provide strong
support
Ceiling
mounting
plate
Recessed
Outlet box
Fig. 2
Fig. 4
Fig. 3
Fig. 1
Outlet box
Outlet box
