Installation Installation

Outer drain hose installation

Outlet

9 10

1. Insert the outer drain hose into the intake on side of washing machine.

2. Push the outer drain hose into the washing machine, and then x it by spring ring. Insert the outer drain

hose properly to avoid water leakage.

3. When the washing machine is running, please lay down the outer drain hose and make sure it does not

entangle. The height of drain hose should be lower than 6cm, in order for the washing machine to spin

properly.

Anti-rat bottom board installation

• After installing the washing machine, take out the anti-rat bottom board. Turn upwards the board showing

“up” and insert it from the back side of washing machine. (If the anti-rat bottom board does not insert

completely, it will produce noise when spinning.

• Install the xed screw in the screw intake.

Lower than 6cm

1 2 3

1. Select the appropriate type of outlet as shown in the gure.

2. End of outlet spout should be more than 10mm, or the connector cannot be assembled.

3. Water leakage is possible from here.

1 2 3

The installation of water inlet hose

1. Unscrewing the part “a” from the water faucet.

2. Respectively attach the water inlet hose to the water faucet.

Note: Do not over tighten. Damage to the valve can result.

3. Run water through both faucet and inlet hose,into a bucket or laundry tub,to get rid of particles in the water

line that might clog the inlet valve screen.

4. Attach the hose connected with the water faucet to the water inlet valve.

Note: Do not overtighten.Damage to the valve can result.

5. Check for leak

• Swing the water inlet hose gently to conrm if it’s suitable.

• Turn on the water faucet and check for leak.A small amount of water might enter the washer. You will

drain this later.

1 2 4
