Specications
7 8
Normal
WM120A Control Panel
Parts Identication
1. Power On/O button
Press the Power button to turn on the power. After power-on, press the Power button to turn o the power.
After the power is turned on, after 5 minutes, if the washing machine is started without pressing the Power
button, the unit will automatically power o.
2. Start/pause button
After turning on the power, press the Start/Pause button to start. Press the Start/Pause button while running
to pause. Press the Start/Pause button while paused and start again.
3. Program
Press this button to choose the desired program.
Normal: standard washing procedure that automatically adjusts the appropriate water level
according to the amount of clothing.
Blanket: washing of large fabrics such as blankets.
Speedy: to wash the slight dirty clothes.
Gentle: to wash wool or underwear.
Air dry: to dry the tub and clothes to some extend
Heavy: to wash the big clothes.
DIY Memory: memorizing the last set of procedures.
Economic: to wash clothes by saving water and electricity.
Kids Wear: to wash baby clothes
Tub clean: to clean the tub when it is idled.
4. Preset: Press the 【Preset】button to set the preset time.
5. Wash: The washing time can be adjusted and set.
6. Soak: Select time of soak by pressing this button.
7. Rinse: The rinsing times can be set.
8. Spin: The spinning times can be set.
9. Child Lock combination Button
After the program starts, press the buttons of 【Rinse】 and 【Spin】 for 1.5 seconds. After one buzzing,
the washing machine enters the "Child Lock" state, repeated operation can cancel the "child lock".
10. Water level button
According to the loading of clothing to press "Water level" button to choose the right water level. The
washing machine determines the weight of the clothes and automatically sets the water level according to
the results of the fuzzy program. Some programs have no water level buttons that are invalid or not
adjustable.
12345
Model
Voltage
Wash/Spin Power
Wash/Spin Capacity
Water Level Volume
High (Litres)
Low (Litres)
Spin Speed
Net Weight (kg)
Gross Weight (kg)
Product Dimension (LxWxH)mm
Box Dimension (LxWxH)mm
WM80A
220-240V~ 50Hz
420W
8kg
62L
20L
720rpm
33.5kg
38kg
600 x 595 x 955 mm
650 x 650 x 1015 mm
WM100A
220-240V~ 50Hz
600W
10kg
78L
33L
670rpm
37kg
42kg
630 x 640 x 1015 mm
680 x 680 x 1050 mm
WM120A
220-240V~ 50Hz
600W
12kg
88L
25L
660rpm
45kg
51.5kg
610 x 630 x 1010 mm
685 x 705 x 1075 mm
Place the washing machine on the at and solid ground
Installation
1. Please do not put the package base (plastic support) under the washing machine, because it will produce
noise and damage the washing machine.
2. Place the washing machine on the at and solid ground.
3. Please keep the distance of more than 15cm from surroundings wall, for proper ventilation avoid noise
during spin function.
Horizontal adjustment
Shake the washing machine, make sure it is fastened.
• Loosen the locknut and turn the adjustor to avoid shaking.
• If there is no shaking, please turn the locknut into tight.
• The inclination angle of the washing machine should not be more than 2 degrees.
Do not obstruct the openings of the bottom face with carpet etc.
!
15cm
and above
• Conrming horizontal level as the picture showing.
