25
INSTALLATION OF THE RANGE
Figure. 7
The range is equipped with a seal to prevent the liquids through the cavities into the cabinet. In order to
place this seal, adhere the seal as shown in the figures above. Turn the range upside down and remove the
protective tape of the rubber seal and adhere it to the range; both ends of the seal should meet each other.
Install the mounting sheets as shown in figure 5 by help of screw. And place the range in the opening on the
counter.
Figure 7 shows the size to which the counter will be cut for installation of the range. Place the prepared
range into the counter cut to these sizes. If you will use the range on the built-in oven, observe the figures
9 and 10 for proper air circulation between the oven and range.
Figure 8 Figure 9
Start to use after you remove the protective film on Inox surface.
WIRING
You should definitely use an earthed line for the product!
The manufacturing firm shall not be responsible for any damages that may occur if the product
is used without the earth.
ATTENTION
Electric shock, short-circuit or fire risk arising from the installation performed by any
unprofessional persons! The product should be connected to the mains only by an authorized
and qualified person and the warranty of the product starts only after correct installation.
KGH 3212 / 3231
KGH 6431 / 6423 / 7523
