13
PRODUCT INSTALLATION
Install Instruction
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be recessed or built-in.
• The refrigerator should be placed in a well-ventilated indoor place; the ground shall be at and sturdy.
• Keep away from heat and avoid direct sunlight. Do not place the refrigerator in moist or watery places to
prevent rust or reduction of insulating eect.
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation of freezing capability and
increased electricity costs. Both sides of the refrigerator should be grater than 4 in(100mm) from the
adjacent walls, and the refrigerator back against the wall distance not more than 3 in(
＜
75mm).
＞4 in(100mm)
＞4 in(100mm)
＞4 in(100mm)
＞4 in(100mm)
＞4 in(100mm)
＜3 in(＜75mm)
Disassembly of refrigerator doors/drawers
In some cases you need to remove the fridge doors and drawer doors to move the refrigerator through a
doorway. The doors can be removed by the following steps. IF NOT NECESSARY, DO NOT REMOVE THOSE
DOORS.
• TOOLS REQUIRED:
3/8" Socket wrench set Phillips screwdriver 3/16" Allen wrench
• DISASSEMBLY OF REFRIGERATOR DOORS:
1. Use screw driver to remove the 3
screws, and then remove the upper
hinge cover of the left door.
Pull the hinge cover in
this direction
