10 English
Hand nozzle
The hand nozzle is used for cleaning small areas that
can be washed down, shower cubicles and mirrors.
1. Slide the hand nozzle onto the steam nozzle or
steam gun.
Illustration H
Illustration I
2. Pull the cover over the hand nozzle.
Spotlight nozzle
The spotlight nozzle is suitable for cleaning areas, joins,
fittings, drains, sinks, WCs, blinds or radiators that are
difficult to access. The closer the spotlight nozzle is to
the soiled area, the greater the cleaning efficiency will
be as the temperature and steam volume are at their
highest at the nozzle opening. Larger lime deposits can
be treated before steam cleaning with a suitable deter-
gent. Allow the detergent to soak in for
approx. 5 minutes and then steam it off.
1. According to the hand nozzle, push the open end of
the spotlight nozzle onto the steam nozzle or steam
gun.
Illustration H
Illustration I
Round brush
The round brush is used for cleaning stubborn dirt.
Stubborn dirt can be removed more easily by brushing.
ATTENTION
Damaged surfaces
The brush may scratch sensitive surfaces.
It is not suitable for cleaning sensitive surfaces.
1. Install the round brush on the spotlight nozzle.
Illustration J
Floor nozzle
The floor nozzle is used for cleaning washable wall and
floor coveringse.g. stone floors, tiles and PVC floors.
ATTENTION
Damage due to build-up of steam
Heat and moisture can lead to damage.
Check the heat resistance and steam effect on an in-
conspicuous area using a minimal volume of steam pri-
or to use.
Note
Detergent residues or care emulsions on the surface to
be cleaned can cause streaks during steam cleaning,
but these disappear after repeated use.
몇 CAUTION
Beware of burns to your feet
The floor nozzle/floor cleaning cloth heats up during
steaming.
Hot water may drip out when pulling off the floor cloth.
Only operate or remove the floor nozzle/floor cleaning
cloth with suitable footwear.
We recommend sweeping the floor or vacuum cleaning
it before using the device. In this way the floor will be
cleared of dirt and loose particles before the wet clean-
ing commences. Work slowly on surfaces that are heav-
ily soiled so that the steam has longer to take effect.
1. Connect the extension tubes with the steam gun.
Illustration I
2. Connect the extension tube to the floor nozzle.
Illustration N
3. Attach floor cleaning cloth to floor nozzle.
a Place the floor cleaning cloth with the hook and
loop strips pointing upwards on the floor.
b Place the floor nozzle onto the centre of the floor
cleaning cloth, applying slight pressure.
Illustration O
The floor cleaning cloth will stick to the floor nozzle
of its own accord due to the hook and loop fastener.
Removing the floor cleaning cloth
1. Place one foot on the bottom corner of the floor
cleaning cloth and lift the floor nozzle up.
Illustration O
Note
Initially, the floor cleaning cloth's hook and loop fastener
strip is very strong and cannot be removed from the
floor nozzle easily. After the floor cleaning cloth has
been used several times and washed, it is easier to re-
move from the floor nozzle and it has reached the opti-
mum adhesion.
Care and service
Replacing the decalcification
cartridge
ATTENTION
Device damage and shortened service life
If the replacement intervals (steam switch) for the decal-
cification cartridge are not observed, there is a risk of
device damage and the service life of the device may be
shortened.
Observe the replacement interval.
Note
The service life of the descaling cartridge corresponds
to a water flow rate of approx. 15 litres.
LED display light on the steam switch at the
end of the run time
The required replacement of the descaling cartridge is
indicated as follows:
1 1 hour before the end of the cartridge run time, the
LED display light on the steam switch flashes or-
ange for 30 seconds.
Illustration W
2 Until the descaling cartridge is completely empty,
the steam switch flashes orange for 30 seconds
each time the device is connected to the socket.
3 If the run time of the descaling cartridge is exhaust-
ed, the steam switch flashes orange quickly and
constantly.
The descaling cartridge must be replaced with a
new one.
Illustration X
Note
In this mode, to protect against possible damage to the
device, steam operation is no longer possible. Steam
operation is therefore only possible again after the des-
caling cartridge has been successfully replaced, see
chapter Initial Start-Up
Inserting the decalcification cartridge
ATTENTION
Device damage
There is a risk of damage to the device if the used de-
calcification cartridge is re-used.
Work carefully in order to prevent mixing up the new and
old cartridge.
Note
When steaming for the first time after removing and re-
inserting the decalcification cartridge, the steam jet may
be weak or irregular, and individual drops of water may
