English 13
this symbol are not allowed to be disposed of together
with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Intended use
몇 WARNING
Health risk
Inhalation of dusts that are harmful to health
Do not use the device for vacuuming up dusts that are
harmful to health.
ATTENTION
Damage to the device
Short-circuit due to high levels of humidity
Only use and store the device indoors.
● This universal vacuum cleaner for carpets is intend-
ed for dry cleaning floor and wall surfaces.
● This device is suitable for commercial use, e.g. in
hotels, schools, hospitals, factories, shops, offices,
and rental companies.
Safety information
Battery pack and charger
In addition, read the operating instructions and safety
instructions that come with the battery pack and the
charger.
This device can be operated with all 18 V / 36 Kärcher
Battery Power and Battery Power+ battery packs.
Description of the unit
Overview of LVS 1/1 Bp
Illustration A
1 On/OFF Button
2 Mode button
3 Mode/error indication display
4 Battery release button
5 Battery holder
6 Filtration system release button
7 Dust cup release button
8 Dust cup
9 HEPA 13 Filter
10 Sponge filter
11 Cyclone
12 Suction tube
13 Floor nozzle tube
14 Floor nozzle head
15 Crevice nozzle
16 Crevice nozzle holder
17 Wall mount / Flexomate adapter
18 Screws and dowels
19 *FlexoLink connection
20 *Rechargeable battery pack
21 *Battery charger
* optional accessory, depending on the configuration
Overview of LVS 1/2 Bp
Illustration B
1 On/OFF Button
2 Mode button
3 Mode/error indication display
4 Battery release button
5 Battery holder
6 Filtration system release button
7 Dust cup release button
8 Dust cup
9 HEPA 13 Filter
10 Sponge filter
11 Cyclone
12 Suction tube
13 Floor nozzle
14 Wall mount / Flexomate adapter
15 Screws and dowels
16 *FlexoLink connection
17 *Crevice nozzle
18 *Rechargeable battery pack
19 *Battery charger
* optional accessory, depending on the configuration
Colour coding
● Control elements for the cleaning process are yel-
low.
● Control elements for maintenance and servicing are
light grey.
Initial startup
Installing accessories
LVS 1/1 Bp
● Install the floor nozzle tube and floor nozzle head
together in the direction shown in the illustration.
Illustration C
● Push the floor nozzle onto the end of the suction
tube until it is tight, and push another end of the
suction tube onto the main body.
● Remove the floor nozzle or the suction tube in the
opposite direction of installation.
Illustration D
● Install the crevice nozzle holder on the suction
tube in the direction shown in the illustration. the
crevice nozzle can be stored in the holder.
Illustration F
● Push the accessory, such as the crevice nozzle,
onto the suction fitting of the dust container or
suction pipe until it is tight.
Illustration G
LVS 1/2 Bp
● Push the suction pipe onto the suction fitting of
the main body until it audibly clicks into place.
Push the floor nozzle onto the suction pipe until it
audibly clicks into place.
