2 Operation Controls and Functions
• Front Panel
NO.
Name
Function Description
1
Power button
In shutdown/standby status, press this button to power on;
in power-on status, press this button for 2~3 seconds to
enter standby status.
2
Power LED
The LED will light in green when the product is working
normally, and red when the product is on standby.
3
HDMI LED
The LED will light in green when HDMI input is selected.
4
USB-C LED
The LED will light in green when USB-C input is selected.
5
AUTO LED
The LED will light in green when auto switching is
enabled.
6
IR window
IR signal receiving window.
7
HDMI button
Press this button to select the HDMI input channel.
8
USB-C button
Press this button to select the USB-C input channel.
9
MODE button
Press this button to switch the 8 splicing modes circularly.
10
RES button
Press this button to switch the resolutions of the four
HDMI outputs circularly.
