Fix the exhaust pipe into the adapter, and then fix the other
side of the exhaust pipe into the air outlet vent of the unit.
(anti-clockwise) (Fig. 2).
Fix the adapter into the window slider kit, then half open the
window to meet the width of the window slider kit. The length
of the window slider kit is adjustable (Fig. 3,4).
Incorrect mounting
The bend of the exhaust pipe is very important.
Incorrect mounting can prevent the machine from working correctly.
Take care to prevent any sharp bows or bends of the exhaust pipe.
The exhaust air must flow freely.
WARNING : The length of the exhaust pipe is specially designed according to the specification of
this product. Do not replace or prolong it with your own private hose as this could cause mal-
function.
Maximum developed length of the exhaust pipe is 1500mm. Use the shortest possible length.
When mounting, we advise to keep the exhaust pipe in a horizontal position.
TKG ACM 1008 S
10
