Kali Audio SM-5 Users’ Guide 9
Full Specifications
SM-5
Self-Powered: Yes
Amplifier: Class D
Amplifier Power: 225 W
HF Driver: 1-Inch Metal Alloy Dome Tweeter
Midrange Driver: 4-Inch Optimized Profile Paper Cone
LF Driver: 5-Inch Optimized Profile Paper Woofer
LF-to-Midrange Crossover: 280 Hz
Midrange-to-HF Crossover: 2800 Hz
Frequency Response: (-10dB) 39 Hz- 25 kHz
Frequency Range: (+/-3dB) 47 Hz - 21 kHz
Recommended Listening Distance: Up to 4 Meters
Max SPL with peak limiter engaged:
117 dB @ 1m
Loudspeaker THD: (85dB SPL at 1M) <0.75 % from 100-450 Hz, <0.5% above 450 Hz
Inputs:
Balanced Analog over XLR/TRS Combijack
AES/EBU over BNC
RJ45 for Control
Outputs: AES/EBU over BNC thru
Enclosure: Front Ported
Mounting Holes (see page 19)
Top and bottom, spaced 4.25 x 2 Inches (108 x
50.8 mm)
Height 15.6 Inches (39.6 cm)
Width: 7.9 Inches (20 cm)
Depth: 9.8 Inches (24.8 cm)
Weight: 21 lbs (9.5 kg)
